La resina è il materiale più importante per la stampa 3D LCD/SLA, che può essere utilizzata per produrre direttamente oggetti stampati in 3D. È un tipo di materiale per la stampa di oggetti nelle stampanti 3D, in particolare per le stampanti 3D da scrivania.

Inoltre, la resinaè il modo più semplice per iniziare con la stampa 3D, ma potresti confonderti quando si tratta di impostazioni della stampante 3D in resina, non preoccuparti, siamo qui per scrivere le migliori impostazioni della resina per la Anycubic stampante 3D in resina di seguito.

anycubic photon workshop resin settings

NOTE:

1. Se l'ambiente di stampa è inferiore a 68°F/20°C, si consiglia di aumentare il tempo di esposizione del 30% e di ridurre la velocità di sollevamento del 30%.

2. I dati provengono dal laboratorio Anycubic e sono solo di riferimento.

3. Diversi parametri di stampa e processi di post-elaborazione presenteranno risultati diversi. Se riscontri problemi durante la stampa, non esitare a contattare il nostro servizio clienti per assistenza.

4. I seguenti parametri di riferimento per l'elaborazione sono adatti allo stato energetico predefinito in fabbrica della stampante Resin 3D. Se l'energia luminosa viene regolata, i parametri di elaborazione di riferimento devono essere regolati di conseguenza.

5. Se non riesci ancora a stampare con i parametri predefiniti, contatta il nostro servizio clienti per una guida professionale.

Impostazioni di stampa per Photon S

Tipo di resina Resina di base Resina vegetale Resina resistente Resina Lavabile ad Acqua Standard Resina+ Resina simile all'ABS+ Resina+ UV Vegetale Resina simile all'ABS Pro Resina Alta Trasparente
Altezza dello strato 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm
Tempo di esposizione 8s 8s 8s 8s 9s 9s 9s 9s 12s
Tempo di spegnimento della luce 1s 1s 1s 1s 1s 1s 1s 1s 1s
Conteggio strati inferiori 6 6 6 6 6 6 6 6 6
Tempo di esposizione inferiore 60s 60s 60s 60s 60s 60s 60s 60s 60s
Distanza di sollevamento 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Velocità di sollevamento 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Velocità di ritiro 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Livello di antialiasing 1 1 1 1 1 1 1 1 1
Superficie satinata × × × × × × × × ×

Impostazioni di stampa per Photon Mono

Tipo di resina Resina di base Resina UV Vegetale Resina Artigianale DLP Resina resistente Resina Lavabile ad Acqua Standard Resina+ Resina simile all'ABS+ Resina+ UV Vegetale Resina simile all'ABS Pro Resina Alta Trasparente
Altezza dello strato 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm 0,05 mm
Tempo di esposizione 2s 2s 2.5s 2s 2s 2.5s 2.5s 2-2.5s 2.5s 4s
Tempo di spegnimento della luce 0,5s 0,5s 0,5s 0,5s 0,5s 0,5s 0,5s 0,5s 0,5s 0,5s
Conteggio strati inferiori 6 6 6 6 6 6 6 8 6 6
Tempo di esposizione inferiore 40s 40s 40s 40s 40s 40s 40s 25-30s 40s 40s
Distanza di sollevamento 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Velocità di sollevamento 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 6mm/s 6mm/s 4mm/s 4mm/s 4mm/s
Velocità di ritiro 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 4mm/s 4mm/s 4-6mm/s 6mm/s 6mm/s
Livello di antialiasing 1 1 1 1 1 1 1 1 1 1
Superficie satinata × × × × × × × × × ×

Printing Settings for Photon Mono X

Resin Type Basic Resin Plant-Based Resin DLP Craftman Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 2s 2s 2s 2s 2s 2s 2s 2s 4s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s
Bottom Layer Count 4 4 8 4 4 4 4 6-8 4 4
Bottom Exposure Time 28s 28s 30 28s 28s 28s 28s 30s 28s 28s
Lifting Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Lifting Speed 2mm/s 2mm/s 4mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2-5mm/s 2mm/s 2mm/s
Retract Speed 3mm/s 3mm/s 4mm/s 3mm/s 3mm/s 2mm/s 2mm/s 3-5mm/s 3mm/s 3mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × ×

Printing Settings for Photon Mono X 6K

Resin Type Basic Resin Plant-Based Resin DLP Craftman Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 2.3s 2.5s 2s 2s 2s 2s 2s 2s 4s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s
Bottom Layer Count 6 6 8 6 6 6 6 6 6 6
Bottom Exposure Time 23s 23s 40s 23s 23s 23s 23s 25s 23s 28s
Lifting Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Lifting Speed 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 8mm/s 8mm/s 2mm/s 2mm/s 2mm/s
Retract Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 2mm/s 2mm/s 3mm/s 3mm/s 3mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × ×

Printing Settings for Photon Mono 4K

Resin Type Basic Resin Plant-Based Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 2.3s 2.3s 2s 2s 2s 2s 2s 4s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s
Bottom Layer Count 6 6 6 6 6 6 6 6 6
Bottom Exposure Time 40s 40s 40s 40s 40s 40s 40s 40s 40s
Lifting Distance 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Lifting Speed 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s
Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × ×

Printing Settings for Photon Ultra

Resin Type Basic Resin DLP Craftman Resin Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 2s 2s 2s 2s 2s
Light-Off Time 1s 1s 1s 1s 1s 1s
Bottom Layer Count 4 4 4 4 4 4
Bottom Exposure Time 35s 35s 35s 35s 35s 35s
Lifting Distance 5mm 5mm 5mm 5mm 5mm 5mm
Lifting Speed 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Retract Speed 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Anti-Aliasing Level 4 4 4 4 4 4
Surface Frosted

Printing Settings for Photon Mono SE

Resin Type Basic Resin Plant-Based Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 1.5s 1.5s 1.5s 1.5s 1.5s 1.5s 1.5s 1.5s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s
Bottom Layer Count 6 6 6 6 6 6 6 6
Bottom Exposure Time 30s 30s 30s 30s 30s 30s 30s 30s
Lifting Distance 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Lifting Speed 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s
Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 4
Surface Frosted × × × × × × × ×

Printing Settings for Photon Mono SQ

Resin Type Basic Resin Plant-Based Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.3s 2.3s 2.3s 2.3s 2.3s 2.3s 2.3s 2.3s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s
Bottom Layer Count 6 6 6 6 6 6 6 6
Bottom Exposure Time 23s 23s 23s 23s 23s 23s 23s 23s
Lifting Distance 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm
Lifting Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Retract Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × ×

Printing Settings for Photon M3

Resin Type Basic Resin Plant-Based Resin DLP Craftman Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 3s 2s 3s 2s 2s 2s 2s 2s 4s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s
Bottom Layer Count 4 4 4 4 4 4 4 6 4 4
Bottom Exposure Time 23s 23s 23s 23s 23s 23s 23s 23s 23s 25s
Lifting Distance 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Lifting Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 6mm/s 6mm/s 3mm/s 3mm/s 3mm/s
Retract Speed 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 3mm/s 3mm/s 4mm/s 4mm/s 4mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × ×

Printing Settings for Photon M3 Plus

Resin Type Basic Resin Plant-Based Resin DLP Craftman Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 1.5s 1.5s 2s 1.5s 1.5s 1.5s 1.5s 2s 2s 4s
Light-Off Time 0.1s 0.1s 0.1s 0.1s 0.1s 0.1s 0.1s 0.5s 0.1s 0.1s
Bottom Layer Count 3 3 3 3 3 3 3 3 3 3
Bottom Exposure Time 23s 23s 23s 23s 23s 23s 23s 23s 23s 28s
Lifting Distance 4mm 4mm 8mm 4mm 4mm 4mm 4mm 4mm 4mm 6mm
Lifting Speed 6mm/s 6mm/s 2mm/s 6mm/s 6mm/s 4mm/s 4mm/s 4mm/s 6mm/s 3mm/s
Retract Speed 6mm/s 6mm/s 3mm/s 6mm/s 6mm/s 6mm/s 6mm/s 4mm/s 6mm/s 4mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × ×

Printing Settings for Photon M3 Max

Resin Type Basic Resin Plant-Based Resin DLP Craftman Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 3s 3s 2s 3s 3s 3s 3s 3s 3s 4.5s
Light-Off Time 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s
Bottom Layer Count 6 6 6 6 6 6 6 6 6 6
Bottom Exposure Time 50s 50s 35s 50s 50s 50s 50s 35s 35s 35s
Lifting Distance 10mm 10mm 8mm 10mm 10mm 10mm 10mm 10mm 10mm 10mm
Lifting Speed 2mm/s 2mm/s 3mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Retract Speed 3mm/s 3mm/s 4mm/s 3mm/s 3mm/s 2mm/s 2mm/s 3mm/s 3mm/s 3mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × ×

Printing Settings for Photon D2

Resin Type Basic Resin Plant-Based Resin DLP Craftman Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.8s 2.5s 2.5s 2.5s 2.5s 3s 2.5s 3s 2.5s 4.5s
Light-Off Time 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s
Bottom Layer Count 6 6 5 6 5 5 6 5 5 4
Bottom Exposure Time 30s 28s 28s 30s 28s 35s 30s 28s 28s 35s
Lifting Distance 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm
Lifting Speed 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Retract Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 2mm/s
Anti-Aliasing Level 16 16 16 16 16 16 16 16 16 4
Surface Frosted × × × × × × × × × ×

Printing Settings for Photon M3 Premium

Resin Type Basic Resin Plant-Based Resin DLP Craftman Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 4s
Light-Off Time 0.5s 0.5s 0.5s 1s 0.5s 1s 1s 0.5s 1s 0.5s
Bottom Layer Count 2 2 2 2 2 2 2 2 2 3
Bottom Exposure Time 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s
Lifting Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Lifting Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × ×

Printing Settings for Photon Mono X2

Resin Type Basic Resin Plant-Based Resin DLP Craftman Resin Flexible Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ High Clear Resin
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 4s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s
Bottom Layer Count 5 5 5 5 5 5 5 5 5
Bottom Exposure Time 25s 25s 25s 25s 25s 25s 25s 25s 25s
Lifting Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Lifting Speed 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Retract Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × ×
